Well as of this morning I went digging around in some Java3D websites/tutorials/downloads, and I found out that Java3D really isn’t that complicated if you KNOW what to program/apply/setup.
I’m use to java2D, example: drawing out a shape,texturing it, and letting the KeyListener/cycle update everything, the movement, the graphics.
But it’s not that easy in Java3D J found out…
So far what I have is a basic .obj file being loaded via J3D (No knowledge on J3D so i can’t add movement), basic lighting, and a light color bieng applied to the model.
Picture of status:
Here’s the code: (Only one class at the moment)
/**
* This class creates a very simple window in which a 3D canvas occupies the
* entire window and displays a 3D model loaded from disk.
**/
public class Display extends JFrame implements Runnable, ActionListener,
KeyListener {
public static float absX = 1.9F;
public static float absY = 1.2F;
public static float absZ = 6F;
public static Timer time;
public int sleep = 10;
/** The canvas where the object is rendered. */
private Canvas3D canvas;
/** Simplifies the configuration of the scene. */
private SimpleUniverse universe;
/** The root node of the scene. */
private BranchGroup root;
public static void main(String[] args) {
try {
new Display().setVisible(true);
} catch (IOException ex) {
ex.printStackTrace();
}
}
/**
* Creates a window with a 3D canvas on its center.
*
* @throws IOException if some error occurs while loading the model.
*/
public Display() throws IOException {
configureWindow();
configureCanvas();
conigureUniverse();
addModelToUniverse();
addLightsToUniverse();
root.compile();
universe.addBranchGraph(root);
time = new Timer(sleep, this);
time.start();
}
/**
* Defines basic properties of this window.
*/
private void configureWindow() {
setTitle("Basic Java3D Program");
setSize(640, 480);
Dimension screenSize = Toolkit.getDefaultToolkit().getScreenSize();
int absX1 = (screenSize.width - getWidth()) / 2;
int absY1 = (screenSize.height - getHeight()) / 2;
setLocation(/* absX1,absY1 */200, 200);
setDefaultCloseOperation(JFrame.EXIT_ON_CLOSE);
}
/**
* Defines basic properties of the canvas.
*/
private void configureCanvas() {
canvas = new Canvas3D(SimpleUniverse.getPreferredConfiguration());
canvas.setDoubleBufferEnable(true);
getContentPane().add(canvas, BorderLayout.CENTER);
canvas.addKeyListener(this);
}
/**
* Defines basic properties of the universe.
*/
private void conigureUniverse() {
universe = new SimpleUniverse(canvas);
universe.getViewingPlatform().setNominalViewingTransform();
}
/**
* Loads a model from disk and assign the root node of the scene
*
* @throws IOException if it's impossible to find the 3D model
*/
private void addModelToUniverse() throws IOException {
vpTranslation = new Transform3D();
Scene scene = getSceneFromFile("bin/res/objects/male02.obj");
root = scene.getSceneGroup();
ViewingPlatform vp = universe.getViewingPlatform();
TransformGroup vpGroup = vp.getMultiTransformGroup().getTransformGroup(
0);
/* You can transform the view platform as you do with other objects */
Vector3f translationVector = new Vector3f(absX, absY, absZ);
vpTranslation.setTranslation(translationVector);
vpGroup.setTransform(vpTranslation);
}
public Transform3D vpTranslation;
/**
* Adds a dramatic blue light...
*/
private void addLightsToUniverse() {
Bounds influenceRegion = new BoundingSphere();
Color3f lightColor = new Color3f(Color.BLUE);
Vector3f lightDirection = new Vector3f(-1F, -1F, -1F);
DirectionalLight light = new DirectionalLight(lightColor,
lightDirection);
light.setInfluencingBounds(influenceRegion);
root.addChild(light);
Background background = new Background(new Color3f(Color.LIGHT_GRAY));
background.setApplicationBounds(influenceRegion);
root.addChild(background);
}
public static Scene getSceneFromFile(String location) throws IOException {
ObjectFile file = new ObjectFile(ObjectFile.RESIZE);
return file.load(new FileReader(location));
}
public void keyPressed(KeyEvent k) {
int key = k.getKeyCode();
int right = 39;
if (key == right) {
absY += 2000; // Hoping this would move the model.
Vector3f translationVector = new Vector3f(absX, absY, absZ);
vpTranslation.setTranslation(translationVector);
}
System.out.println(key);
}
public void keyReleased(KeyEvent k) {
}
public void keyTyped(KeyEvent k) {
}
public void actionPerformed(ActionEvent e) {
run();
}
public void run() {
try {
absX += 0.1f; // Tried moving the variables..
repaint(); // Repaint the JFrame or Canvas3D?
Thread.sleep(sleep);
} catch (InterruptedException e) {
e.printStackTrace();
}
}
}
My Questions:
1: Did I setup everything right?
2: Would I repaint the JFrame, or the Canvas3D?
3: How can I interact with the model? (Via rotation/translation/camera angles).
4: Is there any methods that ‘Override’ a loop method for constant updating/initialization?
5: As seen in the picture above, is there any way with Graphics2D or even Graphics to render above that layer? (Example: render fps count?)
